The lab facilitates accurate measurement of hysteresis loops and primary magnetization curves in magnetic materials for modeling purposes in finite element programs such as ANSYS. In addition to magnetic properties, we investigate resistivity, and temperature dependence up to 300 °C in metals and composite materials. We are able to combine the measurements with Ansys modeling.
Room: SC3.83
Main activities
- Investigating non-destructive material testing methods and novel techniques for the magnetic measurement of non-standard samples
- Measuring primary magnetization curves and dynamic and static hysteresis loops of ferromagnetic materials
- Measuring the magnetic susceptibility of para- and diamagnetic materials
- Laboratory and drone-based magnetic field mapping in diverse samples
- Measuring specific losses in sealed samples, up to 2 MHz
Laboratory equipment
- Triaxial and multiple high-sensitivity frequency bandwidth uniaxial gaussmeters
- Magnetic yokes to facilitate sample fastening, and an Epstein device for both small and large samples
- Coercimeter and a Fluxgate magnetometer
- Auxiliary pulse and constant current sources
- Temperature chamber: 20-300 °C +- 0.5 °C
- Magnetic field sources: f 0-10 Hz for open samples, and 20 MHz for sealed ones
- Foerster eddy current defectoscope to allow non-destructive testing of material conductivity and surface cracks.
